Diffusori da incasso
Diffusori che scompaiono all’interno delle pareti grazie al sistema ad incasso filo muro inventato da Garvan Acoustic nel 2006.
Gli altoparlanti appositamente studiati per suonare in casseforme molto ridotte garantiscono una qualità di ascolto unica, mentre l’acciaio utilizzato per la struttura offre una rigidità a prova di interferenze. Le estetiche, totalmente personalizzabili, consentono un’ampia scelta e offrono soluzioni su misura per integrarsi perfettamente ad ogni ambiente.
|
Model |
Image |
Datasheet |
Power (W) |
Loudspeaker Ø (cm) |
Installation size HxWxD (cm) |
 |
RMS/MAX: 45 / 90 |
Loudspeaker 8,0 |
17,0 x 11,3 x 5,5 |
||
 |
RMS/MAX: 45 / 90 |
Loudspeaker 8,0 |
17,0 x 11,3 x 5,7 |
||
 |
RMS/MAX: 90 / 180 |
Woofer 2x 8,8 Tweeter voice coil 2,0 |
28,3 x 17,00 x 5,65 |
||
 |
RMS/MAX: 180 / 360 |
Woofer 4 x 8,8 Tweeter voice coil 2,0 |
44,3 x 17,00 x 5,65 |
||
 |
RMS/MAX: 50 / 100 |
Woofer 13,0 Tweeter voice coil 1,4 |
26,0 x 20,0 x 6,82 |
||
 |
RMS/MAX: 30+30 / 60+60 |
Loudspeaker 2x8,0 |
26,0 x 20,0 x 6,8 |
||
 |
RMS/MAX: 50 / 100 |
Woofer 16,0 Tweeter voice coil 1,4 |
26,0 x 20,0 x 7,8 |
||
 |
RMS/MAX: 120/240 |
Woofer 16,0 Tweeter voice coil 2,5 |
26,0 x 20,0 x 9,5 |
||
 |
RMS/MAX: 50 / 100 |
Woofer 13,0 Tweeter voice coil 1,4 |
25,0 x 25,0 x 6,4 |
||
 |
RMS/MAX: 30+30 / 60+60 |
Loudspeaker 2x8,0 |
25,0 x 25,0 x 6,8 |
||
 |
RMS/MAX: 50 / 100 |
Woofer 16,0 Tweeter voice coil 1,4 |
25,0 x 25,0 x 7,85 |
||
 |
RMS/MAX: 120/240 |
Woofer 16,0 Tweeter voice coil 2,5 |
25,0 x 25,0 x 10,4 |
||
 |
RMS/MAX: 75 / 150 |
Woofer 16,0 Tweeter voice coil 2,5 |
34,0 x 25,0 x 8,3 |
||
 |
RMS/MAX: 75 / 150 |
Woofer 13,0 Tweeter voice coil 2,5 |
34,0 x 25,0 x 7,6 |
||
 |
RMS/MAX: 75 / 150 |
Woofer 13,0 Tweeter voice coil 2,5 |
50,0 x 35,0 x 7,6 |
||
 |
RMS/MAX: 150 / 300 |
Woofer 2x16,0 Tweeter voice coil 2,5 |
50,0 x 25,0 x 8,3 |
||
 |
RMS/MAX: 75 / 150 |
Woofer 16,0 + PS Tweeter voice coil 2,5 |
50,0 x 25,0 x 7,6 |
||
 |
RMS/MAX: 150 / 300 |
Woofer 2x13,0 Tweeter voice coil 2,5 |
50,0 x 25,0 x 7,6 |
||
 |
RMS/MAX: 300 / 600 |
Woofer 4x13,0 Tweeter voice coil 3,2 |
86,0 x 25,0 x 10,0 |
||
 |
RMS/MAX: 75 / 150 |
Woofer 16,0 + PS Tweeter voice coil 2,5 |
34,0 x 34,0 x 16,0 |
||
 |
RMS/MAX: 50 / 100 |
Loudspeaker 13,0 |
25,0 x 25,0 x 8,4 |
||
 |
RMS: 50+50 / 100 |
Loudspeaker 2x13,0 |
50,0 x 25,0 x 10,0 |
||
 |
RMS/MAX: 75 / 150 |
Woofer 16,0 Tweeter voice coil 2,0 |
50,0 x 25,0 x 10,0 |
||
 |
Center Speaker dx o sx |
Center Woofer 16,0 Tweeter voice coil 1,4 Dx o Sx Woofer 16,0 Tweeter voice coil 2,5 |
50,0 x 25,0 x 1,5 |
|
Model |
Image |
Datasheet |
Power (W) |
Loudspeaker Ø (cm) |
Installation size HxWxD (cm) |
|
|
RMS/MAX: 50 / 100 |
Woofer 13,0 Tweeter voice coil 1,4 |
26,0 x 20,0 x 6,82 |
||
|
|
RMS/MAX: 30+30 / 60+60 |
Loudspeaker 2 x 8,0 |
26,0 x 20,0 x 6,8 |
||
|
|
RMS/MAX: 50 / 100 |
Woofer 13,0 Tweeter voice coil 1,4 |
25,0 x 25,0 x 6,4 |
||
|
|
RMS/MAX: 30+30 / 60+60 |
Loudspeaker 2 x 8,0 |
25,0 x 25,0 x 6,8 |
||
|
|
RMS/MAX: 75 / 150 |
Woofer 13 Tweeter voice coil 2,5 |
34,0 x 25,0 x 7,6 |
||
|
|
RMS/MAX: 75 / 150 |
Woofer 16,0 Tweeter voice coil 2,5 |
50,0 x 35,0 x 7,6 |
||
|
|
RMS/MAX: 75 / 150 |
Woofer 16,0 + PS Tweeter voice coil 2,5 |
50,0 x 25,0 x 7,6 |
||
|
|
RMS/MAX: 150 / 300 |
Woofer 2 x 13,0 Tweeter voice coil 2,5 |
50,0 x 25,0 x 7,6 |
||
|
|
RMS/MAX: 300 / 600 |
Woofer 4 x 13,0 Tweeter voice coil 3,2 |
86,0 x 25,0 x 10,0 |
||
|
|
RMS/MAX: 75 / 150 |
Woofer 16,0 Tweeter voice coil 2,5 |
34,0 x 34,0 x 16,0 |
||
 |
Canale centrale RMS/MAX: 150 / 300 Destro o sinistro RMS/MAX: 75 / 150 |
Woofer 13,0 Tweeter voice coil 1,4 Woofer 13,0 Tweeter voice coil 2,5 |
50,0 x 25,0 x 7,6 |
|
Model |
Image |
Datasheet |
Power (W) |
Loudspeaker Ø (cm) |
Installation size HxWxD (cm) |
|
|
RMS 50/100 |
Loudspeaker 13,0 |
25,0 x 25,0 x 7,6 (muro) 25,0 x 25,0 x 8,4 (cartongesso) |
||
|
|
RMS: 50+50 / 100 MAX: 100+100 / 200 |
Loudspeaker 2 x 13,0 |
50,0 x 25,0 x 10,0 |
||
|
|
RMS 75/150 |
Woofer 16,0 Tweeter voice coil 2,0 |
50,0 x 25,0 x 10,0 |
|
Model |
Image |
Datasheet |
Power (W) |
Loudspeaker Ø (cm) |
Dimension HxWxD (cm) |
 |
150 / 300 |
Woofer 16,0 |
80,5 x 27,5 x 12,0 |
||
 |
2 x (150 / 300) |
Woofer 2 x 16,0 |
80,5 x 52,5 x 12,0 |
||
 |
4 x (150 / 300) |
Woofer4 x 16,0 |
80,5 x 88,5 x 12,0 |
||
 |
80+80 / 160+160 |
Woofer 25,0 |
34,0 x 34,0 x 12,1 |
||
 |
400 / 800 |
Woofer 25,0 |
28,0 x 28,0 x 38,0 (box) |
||
 |
1000 / 2000 |
Woofer 32,0 |
35,0 x 35,0 x 40,0 (box) |
